Pro Tips, News & Events

SPN 110 FMI 0. This is a critical engine protection code. The ECM has confirmed coolant temperature above the safe operating ceiling. The red STOP lamp is on. Torque is already being pulled. A timed shutdown is seconds away. On construction and ag machines, the sensor is almost never the real cause. Blocked cooling cores. A tired fan drive. Degraded coolant. Those are the usual ones. Once the code sets, three things happen in sequence. The red stop lamp lights right away. Peak torque is cut and keeps dropping the longer the condition stays active. Maximum engine speed is capped. Shutdown is enabled in calibration. The lamp starts flashing. About 30 seconds later, the engine stops. That gap is a courtesy. Not a diagnostic window. Use it to clear the machine from traffic. Or get the attachment out of the cut. Do not use it to keep working. Different engine families publish the same condition under their own fault numbers. Cummins ISB, ISC, ISL, QSB, and QSX use 151. Detroit DD13, DD15, and DD16 use EEC 61 or 110-0. Navistar MaxxForce, N13, and A26 use SPN 110 FMI 0 natively. Cat C-series use E361 or CID 110-FMI 0 depending on tier. John Deere PowerTech uses 110.00. Owners often see several SPN 110 codes in the same session. Each FMI points somewhere different. FMI 0 means temperature above critical limit, shutdown pending. FMI 3 means signal voltage too high, usually an open circuit or disconnected sensor. FMI 4 means signal voltage too low, usually a short to ground. FMI 15 means temperature high, warning level only, no derate yet. FMI 16 means temperature high, moderate severity, derate active. If FMI 15 or 16 showed up first and you kept working, FMI 0 is the predictable next step.

Master your tractor’s electrical system with our Kubota ignition switch diagram. This guide breaks down terminal functions, standard wire colors, common failure symptoms, and easy steps to replace a faulty switch yourself.

This starter solenoid acts as a heavy-duty switch controlled by a low-current circuit. It features two large copper posts for high-current power transfer, and two smaller threaded terminals for control and ignition assistance. The solenoid itself is grounded through its metal mounting bracket. Here is a detailed breakdown of each terminal and where its wire goes:

John Deere backhoe size chart. The current lineup has five core models. One G-Tier machine and four P-Tier models. The 320 P-Tier also comes in a Heavy-Lift configuration for jobs that need extra dig depth and loader performance. 310 G-Tier runs 69 hp and 13,907 lb. Standard dig depth is 13 ft 8 in. Loader lift at full height is 6,610 lb. Bucket breakout is 9,564 lbf. 310 P-Tier runs 100 hp and 16,217 lb. Standard dig depth is 13 ft 8 in. Loader lift at full height is 6,602 lb. Bucket breakout is 9,512 lbf. 320 P-Tier runs 113 hp and 17,081 lb. Standard dig depth is 14 ft 3 in. Loader lift at full height is 7,390 lb. Bucket breakout is 10,541 lbf. 320 P-Tier HL runs 113 hp and 17,383 lb. Standard dig depth is 15 ft 1 in. Loader lift at full height is 7,244 lb. Bucket breakout is 10,598 lbf. 410 P-Tier runs 116 hp and 18,651 lb. Standard dig depth is 15 ft 11 in. Loader lift at full height is 6,967 lb. Bucket breakout is 10,361 lbf. 710 P-Tier runs 148 hp and 26,422 lb. Standard dig depth is 17 ft 3 in. Loader lift at full height is 9,866 lb. Bucket breakout is 16,539 lbf. A few things worth knowing. Operating weights reflect the value currently published on each model’s product page. Spec PDFs for individual configurations may list different numbers for the same machine. E-Stick dig depth varies with measurement reference. Confirm against the current spec PDF for your serial number before quoting a job. Loader lift at full height and bucket breakout force are reference numbers. Both change with the bucket. The 410 P-Tier runs roughly 6,144 to 7,211 lb depending on bucket type and size. The 710 P-Tier runs about 8,998 to 9,866 lb. When you are matching a machine to a specific loading task, pull the loader section of the spec sheet.

Finding the right ISO VG 46 hydraulic oil equivalent is crucial for heavy machinery. We cover top matches like Mobil DTE 25, explain viscosity grades, and highlight the risks of using SAE 20 or incorrect ISO fluids.

If you install a Battery Ignition Switch on a Magneto engine (like a Briggs & Stratton), turning the key to “RUN” will send 12V battery power directly down the M (Magneto) wire. This will instantly melt your magneto coil under the engine shroud, turning a $15 switch replacement into a $200+ engine teardown. Always buy a switch explicitly labeled “For Magneto Ignition”.

Harley rake for skid steer. A Harley rake finish-grades a yard in one pass. By hand, that is hours of work. It is why so many skid steers keep one mounted. There is a catch. Teeth wear. Bearings wear. So does the drive motor. All on a schedule. Miss the early signs and a cheap parts swap becomes a lost week. The drum turns backwards against the way the machine is travelling. That counter-rotation is the whole trick. As it turns, it lifts dirt, cuts into packed ground, and throws rocks and debris off to the side. Power comes from the skid steer’s auxiliary hydraulics. Oil flows through the quick-connect couplers into a motor mounted above the drum. That motor spins the drum through a chain drive or direct drive setup. The drum rotates at around 200 rpm. Carbide teeth strike the soil and break it loose. Angled side plates channel debris into a windrow. Two gauge wheels ride at the front and set how deep the drum cuts. Lift them and the drum drops in deeper. Drop them and you get a light finishing pass. Most operators start about an inch down, run one pass, then go another inch deeper only if the ground is still rough.

Choosing between a 2-stage vs 3-stage snow blower depends on your winter weather. While 2-stage models offer reliable clearing for most homes, 3-stage units add an accelerator to crush heavy ice and deep, wet slush.

Choosing the right oil is as important as knowing how much oil the engine holds. Kohler recommends using SAE 10W-30 oil for general-purpose use in temperatures ranging from 0°F to 100°F (-18°C to 38°C). If you live in extremely hot conditions or need heavy-duty use, SAE 30 oil may be more appropriate, as it offers better protection in higher temperatures. Conversely, for colder climates, 5W-30 oil is often recommended due to its superior cold-start properties.

Beet juice for tractor tires is a non-toxic liquid ballast that adds crucial weight for traction without rusting your rims. This guide covers where to buy it, expected costs, and step-by-step DIY filling instructions.

Boom lift repair and maintenance cost. A mid-size telescopic boom runs about $3,500 to $4,500 a year in routine upkeep. Unplanned repairs add another $2,000 to $4,000. That lands near 4 percent of the machine’s new price. Keep scheduled service and surprise repairs on separate budget lines. The repair or replace decision gets clearer that way. Quarterly inspections, one annual inspection, and hydraulic fluid service on a 60-foot telescopic unit worked out to $3,545 in planned maintenance. That is the scheduled side only. With unplanned repairs included, the annual figure moves to $6,045–$7,545. Your number may be lower on a newer electric unit. It may run much higher on an older diesel with worn hoses, aging controls, and a thin service history. Hours matter too. A machine working 800 to 1,200 hours a year needs more attention than one used occasionally.

When your Kohler engine (like Command CV17) refuses to start, or when you turn the key and hear nothing but dead silence, it’s easy to blame the ignition switch immediately. However, before you buy a replacement and start wiring, it’s essential to understand how your Kohler engine’s system actually works. This helps save you a lot of money by avoiding the wrong parts and costly engine repairs due to miswiring.
