A Fleetguard filter cross reference helps you find replacement numbers faster when the original part is not available. It is especially useful when comparing brands across air, fuel, lube, and hydraulic applications. This guide brings together a practical filter cross-reference chart to help reduce ordering mistakes and speed up the search process.
Fleetguard Filter Cross Reference Tables
In day-to-day maintenance, part numbers may vary across suppliers, service histories, and installed components. Having the main cross-reference numbers in one place makes it easier to review options before checking final dimensions and application details.
A filter cross-reference is a useful lookup tool, but it should not replace final fit verification. It helps identify equivalent part numbers across brands, but dimensions, thread size, gasket design, pressure rating, and application details should still be checked before ordering.
Below are direct cross-reference tables organized by filter type for faster lookup.
Air Filter Cross Reference
Air filters protect the engine by trapping dust and debris before they enter the intake system. A clear filter cross-reference makes replacement searches easier, especially when multiple brands are involved.
The table below lists common air filter cross-reference numbers.
| Fleetguard | Baldwin | Donaldson | FRAM | Luber-Finer | WIX |
|---|---|---|---|---|---|
| AF25139M | P527682 | DBA5069 / EAF5069 / P150869 / P527682 / P535717 | CA7140 | LAF1849 | 46556 |
| AF25247 | RS3539 | EAF5100 / P534816 | CA8180 | LAF4816 | 42971 / 46843 |
| AF25707 | RS4636 | P606503 | CA9346 | LAF0109 | 46870 |
| AF26103 | RS4862 | P613336 | CA10305 | LAF6663 | 49088 |
| AF26235 | PA4857 | P604922 | PA10181 | CAF24003 | 24318 |
| AF26405 | PA4681 | P606555 | PA10187 | CAP24003 | 49084 |
| AF26453 | PA4985 | P614221 | PA10184 | CAF24005 | 24316 |
| AF27958 | PA679 | P628355 | N/A | CAP24015 | 24466 |
| AF879NF | PA2363XP | DBA5038 / EAF7038 / EAF5038 / P181038 | N/A | LAF5026MXX | 42440NP |
| AF899NF | PA2453XP | DBA5040 / EAF7040 / EAF5040 / P181004 | N/A | LAF1818MXX | 42238NP |
Before ordering an air filter, check:
- outer diameter
- inner diameter
- overall height
- seal design
- primary or secondary use
Fuel Filter Cross Reference
Fuel filters help keep contaminants out of the fuel system and protect injectors from damage. A fuel filter cross reference is especially useful when older service records show different brands for the same machine.
The table below lists common fuel filter cross-reference numbers.
| Fleetguard | Baldwin | Donaldson | FRAM | Luber-Finer | WIX |
|---|---|---|---|---|---|
| FF2203 | BF7760 / BF8440 | P552203 | P10272 | LFF2203 | 33691 |
| FF5369W | PF7620 / PF7621 / PF7680 / PF7744 | P550414 / P550463 / P550757 / P550969 | CS7772A | L3578FN | 33451 / 33651 / 533651XE |
| FF63009 | N/A | N/A | N/A | LF3009 | N/A |
| FK48555 | PF9924KIT | P550954 | N/A | L5091F | 33849 |
| FK13850NN | PF9908KIT | P551063 | N/A | L5104F | WF10103 |
Equivalent numbers from different brands may use different naming patterns, so the prefix does not always match across manufacturers.
Before ordering a fuel filter, confirm:
- filter type
- thread size
- gasket size
- overall height
- drain or bowl details
- sensor fitting if used
Lube/oil Filter Cross Reference
Lube filters remove harmful particles from engine oil and help protect internal engine components. It is also called an oil filter. An oil filter cross reference can make maintenance planning easier, especially when comparing Fleetguard filters with other brands.
The table below lists common lube filter cross-reference numbers.
| Fleetguard | Baldwin | Donaldson | FRAM | Luber-Finer | WIX |
|---|---|---|---|---|---|
| LF14000NN | BD50000 | P550900 | PH8691A | LFP9001XL | WL10107 |
| LF17511 | P551005 | P7505 | 57909 | LP5090 | 57909 |
| LF3000 | P553000 | BD103 | 51748MP | LFP3000 | 51748MP |
| LF3620 | B495 | P552100 | PH7405 / PH7405A | LFP2160 / LFP2160TRT | 51971 / 51971MP |
| LF3654 | B7409 / B7685 / BK6656 / BK6658 / BK6658A | P550947 / P559647 / P559664 / P903271 / P903272 / P903273 | P9407 | LFP8642 | 24565 / 24980 / 51680 |
| LF3675 | B7600 | P550169 / P550519 / ELF7364 | PH49A | LFP3191 | 51791 |
| LF3883 | B7030 | P550367 / P550512 / P550813 | PH7138 | LFP2285 | 51799 |
| LF3970 | B7177 | P550428 / P550819 | PH8942 | LFP3729 | 57028 / 57182 |
| LF670 | B96 / B7989 | ELF7670 / P550081 / P550671 / P556170 | PH3612 | LFP670 / LK255C | 24870 / 51670 |
| LF691A | B7299 / B99 / B99MPG / B99SS | ELF7405 / P551808 / P554005 / P556170 | PH3335 | LFP4005TRT / LFP4005XL / LK255CA | 51792 / 51792MP / 51792XD / 57792 |
| LF9025 | BD7250 / BK6652 | P550656 / P552025 | PH9971 | LFP9025 | 57744 / 57744CE / 57744XD / 57745 |
| LF9070 | BD7153 | P550949 | PH8690 | LFP9000 | 57745XD |
Before ordering a lube filter, confirm:
- thread size
- gasket diameter
- overall length
- bypass valve type
- anti-drainback design if required
Hydraulic Filter Cross Reference
Hydraulic filters help protect pumps, valves, and other system components from contamination. A hydraulic filter cross reference can help narrow down replacement options before final fit verification.
The table below lists the hydraulic filter cross-reference numbers included in this guide.
| Fleetguard | Baldwin | Donaldson | FRAM | Luber-Finer | WIX |
|---|---|---|---|---|---|
| HF35296 | P550606 | BT8460 | 57701 | LFH8737 | 57191 |
| HF35476 | P573482 | BT8460 | 57191 | LFH4984 | 57191 |
| HF35541 | P174914 | PT8891-MPG | 571127 | LH8781 | 57127 |
Before buying, check:
- micron rating
- pressure rating
- collapse strength
- seal material
- overall dimensions
- line position in the system
How to Verify a Filter Cross Reference Before Buying?
A filter cross reference is a useful lookup tool, but it should not be treated as a final fit guarantee. It helps identify equivalent part numbers across brands, but key specifications should still be checked before ordering.
| Critical Checkpoint | What To Verify | Why It Matters |
|---|---|---|
| Thread Pitch & Size | Confirm the exact thread size and pitch on the old filter. | Prevents cross-threading and leakage under pressure. |
| Outer Dimensions | Measure outer diameter, inner diameter, and overall height. | Ensures the replacement fits the housing or mounting base correctly. |
| Bypass Valve Pressure | Check that the valve opening pressure matches the original specification. | Helps prevent unfiltered oil or fuel from bypassing the filter at the wrong time. |
| Gasket Design | Compare gasket diameter and seal position carefully. | Incorrect gasket dimensions can lead to leaks or sealing problems. |
Once the main specifications have been checked, use the three steps below as a final fit review before placing the order.
1. Match the Complete Part Number
Do not rely on partial numbers alone. A small difference in prefix or suffix can indicate a different filter design or application.
2. Compare Dimensions and Connections
Verify thread size, gasket dimensions, outer diameter, inner diameter, and overall height. If the filter includes a drain, bowl, or sensor fitting, those features should also be confirmed.
3. Verify the Machine Application
Whenever possible, check the replacement against the machine model, engine model, and service history instead of relying only on the installed filter number.
Summary
Using a Fleetguard filter cross reference can save time and improve replacement accuracy when comparing part numbers across brands. FridayParts is a trusted aftermarket parts supplier offering high-quality products at affordable prices, with a vast inventory and wide compatibility for many heavy equipment brands. This helps buyers find practical replacement solutions more efficiently.
